1999-2003 Powerstroke Towmaster 4R100 Transmission (2WD, PTO) (1064442FPTO)

Description

Fits

Year	Make	Model	Engine
1999-2003	Ford	F-250/F-350 2WD	7.3L Powerstroke

BD's stock 4R100 is built to handle stock engine output, featuring an HD transmission pan & most packages come bundled with BD's auxiliary transmission filter kit for added protection!

Part Number: 1064442FPTO

Features

• Increase the durability of your drivetrain
• BD aluminum HD deep pan, increases oil capacity by 6qt
• Re-calibrated accumulator body
• Quicker, firmer shifts
• Full shift kit with line mod valve to increase pressures
• Increased pressure to converter
• Added lube circuits to OD planet
• Added lube and support to output and intermediate shafts
• Drilled and tapped direct and intermediate feeds to prevent leaks at case
• Upgraded OD snap ring
• Machined center support
• Reworked front pump
• Fully rollerized geartrain
• Clutch Count: COAST CLUTCH 2
• Clutch Count: FORWARD 5 (25% increase over stock)
• Clutch Count: DIRECT 5
• Clutch Count: LOW REVERSE 7 (17% increase over stock)
• Clutch Count: INTERMEDIATE 4 (33% increase over stock)
• Clutch Count: OVERDRIVE 4 (33% increase over stock)
• Each transmission is dyno tested
• 1990-2003 include auxiliary frame mounted full flow filter kit
• OEM equipt transmission mounted PTO

Notes

• NOT FOR USE WITH 4:88 OR HIGHER GEAR RATIO
• Remote filter required for inspection with cooler flow rate in GPM at Oil/Air transmission cooler outlet.

Installation

• 5-Hours
• Click Here
• Transmission Filter Kit - Click Here

Warranty

Parts Only - No race abuse covered

• 36-Months
• 150,000
• BD torque converter must be installed at the time of installation of the transmission - use of a 3rd party or OE converter will invalidate the transmission warranty.
