2005-2026 Powerstroke 4x4 Caster Sleeves (8612-24)

Description

Fits

Year	Make	Model
2005-2007	Ford	F-250/F-350 w/ 6.0L Powerstroke
2008-2010	Ford	F-250/F-350 w/ 6.4L Powerstroke
2011-2026	Ford	F-250/F-350 w/ 6.7L Powerstroke

Note: These are designed for the 4x4 front axle; fitment not guaranteed on 2wd applications.

Stop the steering wander and bring that factory-fresh stability back to your leveled Super Duty. These high-strength Dana 60 ball joint sleeves add 2.4 degrees of caster, correcting the suspension geometry changes that happen when you lift your Powerstroke 2.5 inches. Precision-machined from 1045 steel and zinc-plated, these sleeves are the secret to maintaining a confident return-to-center feel and straight-line tracking on the highway.

Part Number: 8612-24

Features

• Compatible with the Synergy 2.5" Leveling Kit
• Adds 2.4 Degrees Caster
• Allows for -1 to +0.4 degrees of camber adjustment
• Restores leveled trucks to factory caster specs
• Improves the return to center
• Minimizes Front-End Steering Wander
• High-Strength 1045 Steel Construction
• Corrosion-Resistant Zinc Plating
• 100% Bolt-in Installation

Includes

• (1) Pair of Super Duty Caster Sleeves

Notes

• Maintenance-free, no greasing required.
• Compatible with stock steering components, wheels, and tires.
• Bolts right to factory mounting locations with no modification necessary.

Installation

Click Here For Instructions
