2005+ Powerstroke HD Drag Link (7600-01)

Description

Fits

Year	Make	Model	Engine
2005+	Ford	F-450 & F-550	6.0L, 6.4L, 6.7L Powerstroke

Built specifically for the F-Series platform, this direct bolt-in drag link replacement gives you an immediate upgrade in steering feel & strength. Designed with a slight bend to make sure there are no clearance issues, knocking, and drag link flop with its single plane tie rod end, & also allows you to retain your factory steering stabilizer.

Part Number: 7602-01

Features

• Max extended length: 48"
• Min collapsed length: 45.25"
• Bolts to factory mounts
• No factory drag link components need to be reused
• HD Metal on Metal Tie Rod Ends with oversized 1" shank
• Single Plane tie rod end used on the axle side to prevent unwanted drag link flop
• CNC formed from 1.50 inch x .250 wall DOM tubing
• Powder coat finish
• Use of pinch bolts instead of jam nuts to simplify installation and adjustment

Includes:

• (1) HD Drag Link
• (1) 4152-L Pitman arm tie rod end
• (1) 4153-L Single plane tie rod end
• (1) 3622-10-14-PL Adjuster sleeve
• (2) Pinch bolts & hardware

Additional Info

• Drag link retains the stock steering stabilizer
• Compatible with stock wheels & tires with correct tie rod end adjustment
• Drag Link is bent for suspension articulation clearance
• Fully adjustable without needing to be removed

Notes

• Replacement Tie Rod Ends:
  • Drivers side - 4152-L
  • Passenger side - 4153-L
• Compatible on vehicles with up to 3" ride height
• Backwards compatible with the stock tie rod
• Synergy Premium Copper Infused Anti-Seize 4118 to be used with all threaded components (TRE's and Adjuster Sleeve)
• Synergy tie rod (7602-01) is recommended with Ford F-450 / F-550, but not required
