2013-2026 Cummins 2" Lift Kit w/ Air Ride (BDS1710H)

Description

Click here to customize this Kit

Fits

Year	Make	Model	Type
2013-2026	Dodge/RAM	3500	4WD

The heavy construction, steel fabricated, and powder coated upper coil spacers are pitched and indexed properly to work with the new Ram's unique coil mount. A retaining bolt mounted through an existing hole in the coil bucket maintains proper indexing and holds the spacer securely in place when the coil springs are unloaded.

Part Number: BDS1710H

Features

• 2" Front Coil Spacer

• 1" Rear Spacer

• NX2 Series Shocks
• Extended Bump Stops

• Retains OE driving characteristics
• Clears 35's
• Easy, 100% Bolt-on installation
• Maintains factory like ride quality
• Standard NX2 Nitro shocks with vehicle-specific valving for better control or FOX 2.0 Performance Series shocks for maximum performance on and off-road

Tire & Wheel Combinations:

• 35x12.50 w/ 20x9 and 5" back spacing
• 35x12.50 w/ 17x9 and 5" back spacing

Shock Options:

NX2 Nitro Series

• Nitrogen-charged
• Twin-tube design

• 10-stage velocity-sensitive valving

• Dual-welded ends for increased strength

• 1-3/8-inch high-flow piston

• Self-lubricating seals

• Silver powder coat finish

FOX 2.0 Performance Series

• 2-inch Impact extruded aluminum body
• Internal floating piston (IFP) monotube design
• CNC machined 6061-T6 aluminum mounting ends

• Massive 5/8-inch hard chrome plated heat-treated alloy steel shaft

• Race-developed high-flow piston design

• Application-specific valving to maximize performance

• Long-lasting clear anodized finish

Notes

• Fits OE equipped air ride systems only

Installation

Installation Guide

Difficulty: 3 (where 1 = easiest and 5 = complicated)
