2013-2025 Cummins Coil Spring Isolator Support (115-91310)

Description

Fits

Year	Make	Model	Engine
2013-2025	Dodge Ram	3500 4WD	6.7L Cummins
2014-2025	Dodge Ram	2500 4WD	6.7L Cummins

The front coil spring buckets on these trucks have a protrusion that is very short, offering less than ideal support for the rubber coil spring isolator. On lifted or leveled trucks, this lack of support can cause the rubber isolator and coil spring to slide forward and rub the frame, creating noise.

There are two separate OEM spring isolators that Ram offers on these trucks. The Power Wagon has a rubber isolator with part number 68268825AA, which has a smaller inside diameter (3-1/4") and will not fit over this add-on support. Models other than the Power Wagon have a rubber isolator with part number 05168566AB with a larger inside diameter (3-7/8"),  which is required to fit over this add-on support kit.

Part Number: 115-91310

Features

• No fabrication required
• 100% bolt-in
• Extended support for the OEM front coil spring isolator

Installation

• Click Here 7455

Notes

• Not applicable for use with Power Wagon isolator p/n 68268825AA

Warranty

Parts Only

• Limited Lifetime Warranty - Cognito branded products
