2014-2018 GMC 1500 7" Big Lift Kit w/ Aluminum Suspension (44-3470)

Description

Fits

Year	Make	Model
2014-2018	GMC/ Chevrolet	1500

A significant amount of engineering and development go into making these big lift kits work competently in your 1500. From tubular upper control arms to retain your factory turning radius and minimizing track width, allowing you to clear 35" tires. Lower strut extensions with TCT bushings allow you to retain the factory struts with no rotation required and provide an accurate pivot point that will never compromise the factory ride quality or handling. Effectively providing you with improved ground clearance, incredible articulation, and predictability for one amazing off-road ride over any terrain.

Part Number: 44-3470/ 44-34720

Features

• TCT lower bushings to provide a precise pivot point that maintains the factory ride
•  Boxed steel front/rear cross members and full-width front skid plate are constructed of thick 3/16" plate steel while also allowing for the use of the OE front plastic gravel guard
• 1/4" boxed plate steel differential drop brackets feature a double gusset & boxed center rib to take the abuse of front differential torsional twisting
• 3/16" thick plate steel rear lift blocks
• Built-in bump stop landings and an offset pin design to properly center the axle & specific angles to the blocks to retain the proper pinion angle
• Bilstein or Falcon 1:1 shocks included

Tire Fitment:

• Max tire: 35x12.50 on 9" wide wheel with -12 offset.

Notes

• Not for use on AWD applications
• Will work with trucks equipped with or without front MagneRide

Installation

• ReadyLIFT Suspension Inc. and/or Dirty Diesel Customs are NOT responsible for any damage or failure resulting from improper installation.
• Click here for installation instructions
