Description

Fits

Year	Make	Engine
2003-2007	Ford Super Duty	6.0L Power Stroke

The Stealth Mach 2 Turbo is an upgraded stock-appearing turbocharger for 2003-2007 Ford Super Duty trucks with the 6.0L Power Stroke diesel engine. Built for serious airflow and strong drivability, this charger is designed to support everything from tune-only trucks to higher-power competition-focused builds.

With a billet compressor wheel, oversized turbine, high-flow vanes, matched unison ring, ported exhaust outlet, and 360-degree thrust bearing, the Stealth Mach 2 is built to reduce drive pressure, improve EGT control, retain usable throttle response, and deliver strong power potential without giving up the factory-style fitment.

Part Number: CPS200333

Supersedes: DM1583090302000

Features

750HP capable in competitive use
67mm billet compressor wheel
77.5x71mm turbine
Stock-appearing design
15mm billet high-flow vanes with matched unison ring and proprietary dowel pin spacing
Ported exhaust outlet
Fully functional exhaust brake
Quick spool-up for usable horsepower
Wide torque curve

Notes

Higher power levels require proper supporting modifications
A 6-blade compressor wheel option may be louder, but is not recommended for towing at higher altitudes

Additional Info

Billet Compressor Wheel

67mm compressor wheel is milled from high-strength 7075 aluminum
11-blade design is engineered to maximize peak power while reducing the potential for surge
Designed with careful MWE groove width, MWE groove placement, and diffuser clearance for improved power and drivability

Turbine Wheel

77.5x71mm turbine is larger than the factory turbine and Garrett Powermax turbine
Larger turbine helps reduce drive pressure under heavy load
Supports near 1:1 drive-to-boost ratio under most operating conditions

Vane And Unison Ring Assembly

15mm billet high-flow vanes provide increased exhaust flow
Matched unison ring actuates the taller turbine inducer and larger vanes
Proprietary dowel pin spacing supports proper vane operation

Durability And Exhaust Flow

360-degree thrust bearing helps minimize thrust wear during competition use
Ported exhaust outlet improves exhaust flow
Lower drive pressure helps increase power and reduce EGTs

Warranty

One Year Limited

OE Replacement Part Numbers

725390-5006
720523-5003
743250-5024
743250-5013
743250-5025
743250-5014
GT3782VA
743250-5014S
1832159C91
1845178C98
720523-9003
725390-5003
725390-5003S
720523-9005
725390-9001
725390-9002
777469-5001S
170-025-1152
170-025-0110
1837984C91
1837984C94
1832160C91
1840054C98
1870714C91
5010089C95
1846764C91
3C3Z6K682CCRM
3C3Z6K682AARM
3C3Z6K682BARM
3C3Z6K682
CBRM743250-5013S
743250-9001
743250-9002
743250-9004
743250-9013
772441-5001S
170-025-1179
170-025-0111
1843761C93
1854480C91
1846767C91
1846765C91
1845322C91
4C3Z6K682CDRM
4C3Z6K682BA
4C3Z6K682CBRM
4C3Z6K682AARM
4C3Z6K682ARM
4C3Z6K682CCRM
743250-9005
743250-9014
170-025-1180
170-025-0109
1832255C91
1876493C91
5010147R93
5010399R91
1854593C91
1858116C91
5C3Z6K682CCRM
5C3Z6K682BA
5C3Z6K682DA
5C3Z6K682CARM
5C3Z6K682AA
5C3Z6K682CA
5C3Z6K682A
