2000-2010 Powerstroke C&C 40 Gallon After Axle Replacement Fuel Tank (10-1002-1)

Description

Fits

Year	Make	Model
2000-2003	Ford	F-350 w/7.3L Powerstroke
2000-2003	Ford	F-450 w/7.3L Powerstroke
2003-2007	Ford	F-350 w/6.0L Powerstroke
2003-2007	Ford	F-450 w/6.0L Powerstroke
2008-2010	Ford	F-350 w/6.4L Powerstroke
2008-2010	Ford	F-450 w/6.4L Powerstroke



The S&B 40 Gallon 10-1002 is a replacement fuel tank for your Powerstroke that can save you from possibly expensive damage to your fuel system and engine. The problem is the Ford Factory after-axle fuel tank has a coating on the inside that can become unstable over time, peeling off and sending contaminates into your entire fuel system.

The S&B tanks on the other hand are made out of Polyethylene, a material that will not delaminate over time and is considered the only true solution to the Ford gas tank delamination problem. Since this tank is an OEM upgrade unit, your sending unit and DTE will read exactly like they did when your truck rolled out the factory gates.

Part Number: 10-1002-1

Features

• 40 Gallons (151 Litres for us Canadians)
• 1-2 Hour Install
• No sump
• No Cutting Required
• OEM Style Sending Unit Mount
• Reuses OEM Skid Plate
• Compatible w/ Gooseneck and 5th wheel

• Dimensions 31.84" X 31.77" X 14.94"
• Drain: Yes

• Embedded fitting thread size: 1/2" NPT
• Ground Clearance compared to OE tank: Same

• Sending Unit: OE
• Straps Included: No
• Sump: No
• Transfer pump ready: No
• Dry weight 28lbs
• Tank Type AFT

Installation

Notes

• Do you have an Auxiliary Fuel Tank? Read why using these with our tanks will void the Lifetime Warranty.
• Skid plates and straps are NOT included. These parts are reused. Torque Spec is 30 in/lbs for sending unit nuts.
• This is a direct replacement to the OEM 40 gallon tank. This and your current OEM tank are the same size and shape. This poly tank resolves the problem of the OEM steel tank delaminating and damaging your fuel system. This tank does NOT fit 1999 trucks.
